| Print head | On-demand Piezo head (4 staggered layout) |
|---|
| Print resolution | Y: 300, 600, 1,200 dpi X: 600, 900, 1,200 dpi |
|---|
| Ink | Type/Color | Hard UV curable ink: ELH-100 (C, M, Y, K, Lc, Lm, W, Cl)
Flexible UV curable ink: ELS-120 (C, M, Y, K, Lc, Lm, W, Cl)
Fluorescent UV curable ink: EFS-150 (Fp, Fy) *1
Primer: PR-200 *2 |
|---|
| Capacity | 1L bottle (ELH-100, ELS-120, EFS-150, PR-200)
250ml bottle (ELH-100, ELS-120, PR-200) |
|---|
| Maximum printable area (W × D) | 2,500 x 1,500 mm (98.4 x 59.1") |
|---|
| Media | Adsorption size | Max. 2,500 x 1,930 mm (98.4 x 76.0") |
|---|
| Thickness | Max. 101.6 mm (4.0") |
|---|
| Weight | Less than 50 kg/m², non concentrated load |
|---|
| Absorption area partitions | 25 mm (1") pitch suction holes |
|---|
| Certifications | VCCI class A, FCC class A, ETL IEC 62368-1,
CE Marking (EMC, Low voltage, Machinery directive, and RoHS),
CB, REACH, RCM, KC, UKCA |
|---|
| Interface | Ethernet 1000BASE-T |
|---|
| Power specification | Single phase AC200-240V±10% 12A or less, Single phase AC200-240V±10% 10A or less |
|---|
| Power consumption | INLET1: 2.88 kVA or less, INLET2: 2.33 kVA or less |
|---|
| Operational environment | Temperature: 15–30 °C (59–86 °F)
Humidity: 35–65% Rh (Non condensing)
Recommended temperature: 20–25 °C (68–77 °F)
Temperature gradient: Less than ± 10 °C/h (± 50 °F/h)
Dust level: Similar to standard office environments |
|---|
| Dimensions (W × D × H) | 4,400 x 2,520 x 1,490 mm (173.2 x 99.2 x 58.7") |
|---|
| Weight | 920 kg (2,028.3 lb) |
|---|
