| HEAD | TOOL | PRESSURE |
Head configurations | TD | A | Pen / swivel cutter 20 – 400g |
| | | Tangential cutter 300 – 1,500g |
| | | Marking gauge roller 1,000 – 5,000g |
| RC | A | Reciprocal cutter 1,500g fixed |
| | B | Tangential cutter 500 – 1,500g |
| | C | High pressure tangential cutter/ marking gauge roller 1,000 – 5,000g |
Effective cutting area | | | CF2-0912: 117 x 90 cm |
| | | CF2-1218: 177 x 120 cm |
Motorization | | | X, Y, Z, Ø axes DC servo |
Maximum speed | | | 50 cm/s |
Accuracy of repeatability | | | Plus minus 0.1 mm |
Maximum cutting depth | TD | | 1 cm |
| RC | | 2 cm |
Media fixation | | | Table with vacuum system and blower function |
Interface | | | RS-232C |
Power consumption | | | Main unit less than 300 VA, |
| | | blower: stated separately |
Dimensions (w x d x h) | | | CF2-0912: 176 x 160 x 110 cm |
| | | CF2-1218: 236 x 190 x 110 cm |
Weight | | | CF2-0912: 140 kg |
| | | CF2-1218: 180 kg |
